Feature:
Wattage: 24W
Pipe Size: 1/4", 1/2", 3/4", 1" optional
Thread type: G1/4"，G1/2"，G3/4" , G1" optional
Internal Diameter: 12MM, 20MM, 25MM, 32MM optional
Working Voltage: DC 12V, DC 24V, AC 220V, AC 110V optional
Type: normally closed (power on, solenoid valve open; power off, solenoid valve close)
Working Temperature: -10℃ ~ +100℃
Operating Pressure: 0~1.0Mpa (0~10kg/cm²)
Material of valve body and coil: 100% Brass
Usage: water, air, diesel, gas, low viscosity fluids
Note: DC 12V or 24V solenoid valve needs to work with a power adapter of 2A or above.
Wattage: 24W
Pipe Size: 1/4", 1/2", 3/4", 1" optional
Thread type: G1/4"，G1/2"，G3/4" , G1" optional
Internal Diameter: 12MM, 20MM, 25MM, 32MM optional
Working Voltage: DC 12V, DC 24V, AC 220V, AC 110V optional
Type: normally closed (power on, solenoid valve open; power off, solenoid valve close)
Working Temperature: -10℃ ~ +100℃
Operating Pressure: 0~1.0Mpa (0~10kg/cm²)
Material of valve body and coil: 100% Brass
Usage: water, air, diesel, gas, low viscosity fluids
Note: DC 12V or 24V solenoid valve needs to work with a power adapter of 2A or above.
| Pipe Size | A | B | C | D (Internal Diameter) |
| 1/4" | 74MM | 41MM | 18MM | 12MM |
| 1/2" | 100MM | 64MM | 52MM | 20MM |
| 3/4" | 107MM | 73MM | 56MM | 25MM |
| 1" | 113MM | 90MM | 68MM | 32MM |
